Spartanburg Facility

115 Coastline Road
Spartanburg, SC 29301
864.574.8050


IATF 16949:2016 Certified
Download Here

Spartanburg Warehouse

  • Total Square Footage
    235,000 Sq. Ft.

  • Unloading Procedures:
    Forklift Side/Rear
    Overhead Crane

  • Maximum Coil Dimensions
    30 Tons / 84" OD / 72" Width

  • Rail Availability
    CSX Incoming/Outgoing via Covered Gondola, 24 Cars Per Day

Multi Blanker
Braner USA

  • Incoming Material

    • Coil Width 12.00–74.00"

    • Coil Weight 60,000#

    • Coil OD Max 72.00"

    • Coil ID 20.00–24.00"

  • Multi-Blanking

    • Max output: 4 blanks across

  • Outgoing Material

    • Blank Width 8.00–72.00"

    • Blank Length 12.00–168"

    • Skid Height 24.00"

  • Material Thickness

    • Stainless .095–.0190"

    • Mild Carbon .135–.0190"

    • Aluminum .135–.0190"

  • Maximum Yield Strength

    • 40,000psi up to .135 thick

    • 60,000psi up to .110 thick

    • 80,000psi up to .095 thick

  • Tolerances

    • Slit Width Tolerance +/- .005

    • +/- .032 length

    • Tighter tolerances by request

  • PVC Application

    • Available Up To 48.00"
      Upon Request

  • Edge Trim

    • .500 Minimum

  • Products Processed

    • Hot Rolled Pickled

    • Cold Rolled

    • Galvanized

    • Tin Plate

    • Preprinted

    • Stainless

    • Aluminum

72" Slitter
Chicago Slitter

  • Incoming Material

    • Coil Width 74.00"

    • Coil Weight 60,000#

    • Coil OD Max 84.00"

    • Coil ID 20.00–24.00"

  • Outgoing Material

    • Coil Width 72.00"

    • Coil Weight 60,000#

    • Coil ID 20.00–24.00"

  • Tolerances

    • Slit Width Tolerance +/- .005

    • Edge Trim Required .500"

    • Minimum Slit Width 1.25"

    • Maximum Cuts Per Pass 30

  • Special Features

    • Roll Tensioning

    • Shimless Tooling

    • Injection Slitter Heads

    • Tungsten Carbide Knives

    • Over/Under Rewind Capabilities

    • Separate Tension Units for Oily or Dry material

    • PVC Application Available

  • Products Processed

    • Hot Rolled Pickled

    • Cold Rolled

    • Galvanized

    • Tin Plate

    • Preprinted

    • Stainless

    • Aluminum
